Wattsaving
Wattsaving HQ7 7kW Smart DC Charger
Wattsaving HQ7 7kW Smart DC Charger
Collapsible content
Product Specification
| Model | Wattsaving HQ7 |
| Output DC Power | Maximum 7kW |
| Input Voltage | 176~264Vac |
| Output Voltage | 200~1000Vdc |
| Frequency | 45-55Hz |
| Current | 22A MAX |
| Efficiency | ≥94% |
| Communication | 4G/Bluetooth |
| Cable Length | 5m/8m |
| Input Wiring | Hardwired |
| Display | 1.52" LCD Screen |
| Input Cord(single-phase) | L, N (Neutral), and PE (Protective Earth) |
| Protection | Over current protection, Residual current protection, Ground protection, Surge protection, Over/Under Voltage protection, Over/Under temperature protection. |
| IP Rated | IP54 |
| Storage Temperature | -40 to 90℃ |
| Operating Temperature | -40℃~50℃ |
| Operating Humidity | 5%~95% |
| Connector | 1 |
| Standards |
GB/T 18487.1-2015 GB/T 27930-2015 NB/T 33001-2018 NB/T33008.1-2018 |
| Dimension (H x W x D) | 405*250*119mm |
| Weight | 9.0kg |
