Wattsaving T240 240kW DC Fast Chargers for EV Charging Business

Wattsaving T240 240kW DC Fast Chargers for EV Charging Business

Type of Connectors
Quantity of Connectors
View full details

Collapsible content

Product Specification

Model Wattsaving T240
Output DC Power Maximum 240 kW
Input Voltage 323~480Vac,380Vac Type
Output Voltage 150~1000Vdc
Frequency 45-55Hz
Current 250A MAX
Efficiency ≥94%
Communication 4G
Cable Length 5m
Input Wiring Hardwired
Display 7-inch LCD Screen
Input Cord(three-phase) L1, L2, L3, N (Neutral), and PE (Protective Earth)
Protection Over current protection, Residual current protection, Ground protection, Surge protection, Over/Under Voltage protection, Over/Under temperature protection.
IP Rated IP54
Storage Temperature -40 to 80℃
Operating Temperature -40℃~55℃
Operating Humidity 5%~95%
Connectors 2
Standards

GB/T 18487.1-2015                                                  GB/T 27930-2015                                                    NB/T 33001-2018                                                    NB/T33008.1-2018

Dimension (H x W x D) 1582*750*455mm
Net Weight 300.0kg
Gross Weight 325.0kg
Warranty 2 Years
