Wattsaving T40 40kW DC Fast Chargers for Home & Business

Wattsaving T40 40kW DC Fast Chargers for Home & Business

Type of Connectors
Quantity of Connectors
View full details

Collapsible content

Product Specification

Model Wattsaving T40
Output DC Power Maximum 40 kW
Input Voltage 323~500Vac,380Vac Type
Output Voltage 200~1000Vdc
Frequency 45-55Hz
Current 125A MAX
Efficiency ≥94%
Communication 4G
Cable Length 5m
Input Wiring Hardwired
Display LCD Screen
Input Cord(three-phase) L1, L2, L3, N (Neutral), and PE (Protective Earth)
Protection Over current protection, Residual current protection, Ground protection, Surge protection, Over/Under Voltage protection, Over/Under temperature protection.
IP Rated IP54
Storage Temperature -40 to 80℃
Operating Temperature -30℃~65℃
Operating Humidity 5%~95%
Connector 1

GB/T 18487.1-2015                                                  GB/T 27930-2015                                                    NB/T 33001-2018                                                    NB/T33008.1-2018

Dimension (H x W x D) 680*500*155mm
Net Weight 50.0kg
Gross Weight 55.0kg
Warranty 2 Years

Get a quote from the factory
