Wattsaving T480 480kW DC Fast Charging Hub

Wattsaving T480 480kW DC Fast Charging Hub

Type of Connectors

View full details

Collapsible content

Product Specification

Model Wattsaving T480
Output DC Power Maximum 480 kW
Input Voltage 323~480Vac,380Vac Type
Output Voltage 150~1000Vdc
Frequency 45-55Hz
Current 1600A MAX
Efficiency ≥94%
Communication 4G / Ethernet
Cable Length 5m
Input Wiring Hardwired
Display 7-inch LCD Screen
Input Cord(three-phase) L1, L2, L3, N (Neutral), and PE (Protective Earth)
Protection Over current protection, Residual current protection, Ground protection, Surge protection, Over/Under Voltage protection, Over/Under temperature protection.
IP Rated IP54
Storage Temperature -40 to 80℃
Operating Temperature -40℃~55℃
Operating Humidity 5%~95%
Connectors 8 - 12
Standards

GB/T 18487.1-2015                                                  GB/T 27930-2015                                                    NB/T 33001-2018                                                    NB/T33008.1-2018

Dimension (H x W x D) 1700*950*1303mm
Weight 625.0kg
Warranty 2 Years
